Stapley Action Garage Door proudly offers the Modern Steel™ Ultra-Grain® Plank garage door, a standout product from Clopay, the leading U.S. garage door manufacturer. Serving Mesa and the Phoenix Metro area for 15 years, we bring this durable, stylish door to Arizona homeowners who value quality and efficiency. The Ultra-Grain® Plank combines the look of wood with the strength of insulated steel, making it an ideal choice for Mesa’s climate and architectural diversity.
Overview of Ultra-Grain® Plank in Modern Steel™
The Modern Steel™ Ultra-Grain® Plank is a high-performance door from Clopay’s Modern Steel™ Collection, model 9130. Its construction is designed for durability and energy efficiency:
- Structure: A 3-layer design with 2-inch Intellicore® polyurethane insulation between two steel layers, delivering an R-value of 18.4, one of the highest in the industry.
- Steel Gauge: 27-gauge exterior steel paired with a 24-gauge interior steel backer, providing a total thickness of 2 inches.
- Finish: Ultra-Grain® coating, a factory-applied, two-step process that replicates wood grain texture over a galvanized steel base, topped with a polyester finish for UV and corrosion resistance.
- Weatherproofing: Tongue-and-groove section joints and a replaceable vinyl bottom weather seal in a rust-proof aluminum retainer block out wind, dust, and rain.
- Hardware: Includes 10-ball nylon rollers, 14-gauge steel hinges, and heavy-duty galvanized springs rated for 10,000 cycles, ensuring reliable operation.
This door weighs approximately 150-200 pounds for a standard 16×7-foot size, depending on window configurations, and meets wind load requirements with optional WINDCODE® reinforcement.
Aesthetic Enhancements from Ultra-Grain® Plank
The Ultra-Grain® Plank design offers distinct visual upgrades, verified through Clopay’s product documentation and customer feedback:
years of Smart Working experience
Features a flush panel with horizontal plank-style embossing, mimicking handcrafted wood doors while maintaining a modern, streamlined profile.
The Ultra-Grain® finish provides a detailed wood texture visible up close, unlike standard steel doors, enhancing curb appeal for homes in Mesa’s contemporary or historic districts.
Available in Ultra-Grain® Medium (a light oak tone), Walnut (a rich brown), and Cherry (a deep reddish hue), each baked on at Clopay’s factory for consistency and durability.
Optional slim (2×18-inch) or long (4×18-inch) windows in clear, frosted, or insulated double-strength glass add light and architectural interest, with snap-in grilles available for customization.
This door suits modern, mid-century, and transitional homes, aligning with Mesa’s growing trend of sleek, functional exteriors.
(480) 655-1255
Maintenance Tips for Modern Steel™ Ultra-Grain® Plank
Maintaining this door is super easy, based on Clopay’s care guidelines and Stapley Action’s service experience:
Cleaning
Wash every 6-12 months with a mild dish soap solution (1/4 cup per gallon of water) and a soft cloth or sponge. Rinse thoroughly to remove dust or salt buildup common in Mesa’s dry climate. Avoid pressure washers or harsh chemicals like bleach, which can damage the finish.
Lubrication
Apply a silicone-based lubricant to rollers, hinges, and springs annually to prevent friction wear. Clopay advises against WD-40, as it attracts dust.
Inspection
Check the weather seal for cracks and ensure the auto-reverse safety feature on the opener works, as per federal regulations (UL 325). Test balance by lifting the door halfway manually; if it doesn’t hold, call Stapley Action for spring adjustment.
Finish Care
The Ultra-Grain® coating resists fading and peeling, but minor scratches can be touched up with Clopay-approved exterior paint matched to the factory color. In Mesa’s heat, this door outperforms wood, which warps or cracks without frequent sealing, requiring only 1-2 hours of annual care versus wood’s 10-20 hours.
Available Styles in Modern Steel™ Ultra-Grain® Plank
Customization options are precise and limited to Clopay’s verified offerings for this model:
Panel Style
Flush with horizontal plank embossing, 4-5 planks per section depending on door height (standard 7 or 8 feet).
Finishes
Ultra-Grain® Medium, Walnut, or Cherry, applied at the factory. Custom painting is possible with exterior latex paint over the steel surface.
Window Configurations
Slim windows (two per section) or long windows (one per section), available in 5/32-inch clear, frosted, or insulated glass. Plastic grilles snap in and out for cleaning or style changes.
Hardware Add-Ons
Compatible with Clopay’s LiftMaster® Elite Series™ 8500W opener, a wall-mounted, Wi-Fi-enabled unit with a 10-year motor warranty, sold separately through Stapley Action.
